LS6125-927S
Boostline Chevrolet LS Connecting Rod, 6.125 in. Length, 0.927 in. Pin, 2.100 in. Journal, 7/16 in. ARP 2000 Bolts, 4340 Steel, Patented Three-Pocket Design, Set of 1.
BoostLine connecting rods are designed and built for the stressful demands of high-powered, forced induction and nitrous LS engines. Proven in the lab and on the track in 2,000HP, eight-cylinder applications, BoostLine rods are forged from premium 4340 steel and utilize a patented, three-pocket design, maximizing strength while minimizing rotating weight. This revolutionary design dramatically improves each rods’ big-end stability under tensile loads and provides a 60% improvement in bending strength and 20% stress reduction in tension compared to H-beam designs, benefits crucial to durability in four-digit-horsepower engines. Each rod is equipped standard with industry leading ARP hardware and is subject to a 26-point, CMM inspection with all critical dimensions provided via an inspection card provided with every set of BoostLine rods. BoostLine connecting rods are the complete package for everything from powerful projects to all-out race cars
- Purpose-Built For Boost High Boost and Nitrous LS Applications
- Forged From Ultra-Strong 4340 Steel
- Patented Three-Pocket Design
- Capable of 2000 HP
- Stroker Clearance
- 7/16 x 1.400 in. ARP 2000 Fasteners
- High Quality APMCO Bronze Pin Bushing
- 26 Point Detailed CMM Inspection Report Included
| Rod Type |
I-Beam |
|---|---|
| Material |
Forged 4340 Steel |
| Center To Center Length |
6.125 IN |
| Average Gram Weight |
694 GR |
| Pin End Bore |
0.927 IN |
| Journal Size |
2.100 IN |
| Main Bearing Bore Diameter |
2.225 IN |
| Big End Width |
0.940 IN |
| Wrist Pin Journal Bushing Width |
1.010 IN |
| Bolt Part Number |
BT71401-2S |
| Bolt Diameter |
7/16 IN |
