BoostLine Audi TT RS 5 Cyl 144mm 22mm ARP 625+ - Connecting Rod Single

$565.34 CAD

BoostLine SKU: bslVW5670-866Splus

Earn [points_amount] when you buy this item.

VW5670-866S+

Boostline Volkswagen 2.5L TFSI TT RS 20V Connecting Rod, 144.00 mm Length, 22.00 mm Pin, 47.80 mm Journal, 3/8 in. ARP 625+ Bolts, 4340 Steel, Patented Three-Pocket Design, Set of 1.

BoostLine connecting rods are designed and built for the stressful demands of high-powered, forced induction and nitrous engines. Proven in the lab and on the track in 1,500HP+ five and six-cylinder engines from the iconic 2JZ to EcoBoost 3.5Ls to Audi RS2s, BoostLine rods are forged from premium 4340 steel and utilize a patented, three-pocket design, maximizing strength while minimizing rotating weight. This revolutionary design dramatically improves each rods’ big-end stability under tensile loads and provides a 60% improvement in bending strength and 20% stress reduction in tension compared to H-beam designs, benefits crucial to durability in four-digit-horsepower engines. Each rod is equipped standard with industry leading ARP hardware and is subject to a 26-point, CMM inspection with all critical dimensions provided via an inspection card included with every set of rods. BoostLine connecting rods are the complete package for every performance build, from powerful projects to all-out race cars.

  • Purpose-Built For Boost High Boost and Nitrous Audi TT RS Applications with 22mm Pin
  • Forged From Ultra-Strong 4340 Steel
  • Patented Three-Pocket Design
  • Capable of 1000+ HP
  • 3/8 x 1.600 in. ARP 625+ Custom Aged Fasteners
  • High Quality APMCO Bronze Pin Bushing
  • 26 Point Detailed CMM Inspection Report Included
Rod Type

I-Beam

Material

Forged 4340 Steel

Center To Center Length

144.00 MM

Average Gram Weight

614 GR

Pin End Bore

22.00 MM

Journal Size

47.80 MM

Main Bearing Bore Diameter

50.610 MM

Big End Width

21.89 MM

Wrist Pin Journal Bushing Width

22.00 MM

Bolt Part Number

BT61501-625

Bolt Diameter

3/8 IN
