OIL PAN, GM LT, SWAP, DRAINBACKS, CAST

20158

Cast Aluminum, Wet Sump, 6 Quart Capacity, 5.5" Deep

Engine Application: GM Gen V LT

Fits: LT Engine Swaps, GM Cars & Trucks w/ Rear Sump, check dimensions for clearance

• Clears up to 4.00" stroke with most steel rods
• Perfect for retrofitting wet sump Gen V LT motors (LT1/LT4/L83/L86) into other applications
• 1/2" N.P.T. drainback provision
• Kit includes anti-slosh baffle, windage tray, oil pickup, required sealing gaskets and O-rings, as well as mounting hardware
• Integral 22mm spin-on oil filter provision with oil cooler port for use with Moroso part No. 22463 or O.E.M. equivalent filter
