Ohlins 95-98 Porsche 911 (993) All Sub Models Road & Track Coilover System

A more than 40 year long tradition of high-end racing commitments and state-of-the-art solutions within advanced suspension technology is now available for street cars all over the world. The focus has been clear from the very beginning – superior road handling without sacrificing comfort in your day-to-day transports. The time of compromises is over. All shocks have suffered through vast corrosion tests according to ISO 9227. The end result is a worldwide 2-year limited warranty on all of our products.

General Features:

• DFV technology (Dual Flow Valve)
• Individual height adjustment
• Rebuildable
• Corrosion salt spray tested (ISO 9227)
• 2 year warranty

Front:

• McPherson strut, upside down
• Compression and rebound damping with one adjuster
• Spring preload adjuster
• Separate ride height adjustment
• Spring rate 60 N/mm
• Aluminum top mounts with adjustable camber

Rear:

• Conventional shock absorber
• Compression and rebound damping with one adjuster
• Spring preload adjuster
• Separate ride height adjustment
• Spring rate 110 N/mm
• Aluminum top mounts (not adjustable)

Purchased Parts Package:

• Coil over kit incl. springs and mounting parts
• C-Spanner (for spring preload adjustment)
• Owners manual

Please note:

For the 2WD version you will need to install original Porsche anti rollbar links. These are not included! Porsche genuine part numbers are:

• Anti roll bar link left 993 343 069 00
• Anti roll bar link right 993 343 070 00

Fits the following vehicles

• Porsche 911 (993) 2WD, year 1996 – 1998

  • Type: 993
  • Variants: MKII
  • TÜV certificate
  • GOCA (BE)

• Porsche 911 (993) 4WD, year 1993 – 1998

  • Type: 993
  • Variants: alle
  • TÜV certificate
  • GOCA (BE)
