ADRO TOYOTA GR86 FULL WIDEBODY KIT W/O DIFFUSER

ADRO TOYOTA GR86 FULL WIDEBODY KIT W/O DIFFUSER

$6,584.99 CAD $7,064.99 CAD Save $480 CAD

ADRO SKU: ADROA18A10-1101

Earn [points_amount] when you buy this item.

Description Availability

A18A10-1101

A sports car built by enthusiasts and for enthusiasts, the GR86 / BRZ has the performance pedigree of a top-tier sports car.

The ADRO widebody kit increases the vehicle’s width by more than five inches on the front bumper and six inches on the rear. The length is also increased by more than five inches with the inclusion of the custom carbon fiber wing and diffuser.

Aerodynamic testing for ADRO’s carbon fiber body kit shows a dramatic increase in downforce for the custom GR86 / BRZ to improve the cornering performance of the package.

Learn more about our GR86 / BRZ widebody kit here.



WIDEBODY KIT SPECIFICATIONS

Toyota GR86 / Subaru BRZ

SKU:


Widebody Kit (No Diffuser): A18A10-1101
Diffuser: A18A10-1301

Compatible with:


2022-2023 Toyota GR86 Base
2022-2023 Toyota GR86 Premium
2022-2023 Subaru BRZ Premium
2022-2023 Subaru BRZ Limited

Full body kit includes:


Front Bumper Extensions
Front Overfenders
Rear Overfenders
Carbon Fiber Side Air Vent Cover
Carbon Fiber Front Lip
Carbon Fiber Side Skirt
Carbon Fiber Diffuser (Only in Kit with Diffuser)

Material:

FRP/ Wet Carbon Fiber
Dimensions:



Front Bumper Extensions: 530 mm x 1910 mm x 613 mm
Front Overfenders: 1,087 mm x 206 mm x 662 mm
Rear Overfenders: 1,244 mm x 258 mm x 707 mm
Carbon Fiber Side Air Vent Cover: 184 mm x 46 mm x 365 mm
Carbon Fiber Front Lip: 585 mm x 1,833 mm x 33 mm
Carbon Fiber Side Skirt: 1,868 mm x 190 mm x 46 mm
Carbon Fiber Diffuser: 527 mm x 1,689 mm x 356 mm

Recommended wheel size:

Front: 18x9-35
Rear: 18x10-35

Weight:

With Diffuser: 30.6 lbs (13.9 kg) total
Without Diffuser: 25.1 lbs (11.4kg) total

What’s in the box:

Front Bumper Extensions
Front Overfenders
Rear Overfenders
Carbon Fiber Side Air Vent Cover
Carbon Fiber Front Lip
Carbon Fiber Side Skirt
Carbon Fiber Diffuser (Only in Kit with Diffuser)
3M Tape
Screws

Installation guide:

Professional installation only

Version:

v1
